| Color: | |
|---|---|
E86
OEM
7117900000
Fitness Digital Smart Watch Phone with Touch Display and ECG Healthy Monitor
Specification:
Main control chip Ultra-low power consumption Nordic52832
Blood oxygen chip Ti high-performance analog front-end AFE4404+2*OSRAM 2703 PD+OSRAM three-in-one LED.
Body temperature sensor: CT1711 array
ECG chip Ti chip 129
Optoelectronic chip Ti AFE4404 + dual OSRAM (OSRAM) 2703
Vibration: silent/vibration, waterproof level IP68
Compatible system Android 4.4 and above, iOS 8.2 and above Screen size: 1.70 inches high-definition color screen TFT 240*280 Screen type: IPS high-definition TFT
Bluetooth: 4.2BLE (low power consumption)
battery 200mAh, charging method: magnetic charge
Charging time: about 3-4H, battery life: 7-15 days of use, 30-40 days of standby
Control mode: full screen touch control
APP name: SmartHealth
| Product Model | E86 | |
| Master Chip | Ultra low power nordic52832 | |
| Blood oxygen | Ti AFE4404 + 2*OSRAM 2703+OSRAM LED | |
| Temperature sensor | CT1711 array | |
| ECG chip | Ti chip 129 | |
| PPG chip | Ti AFE4404 +2*OSRAM 2703 | |
| Virbation | Loundspeaker Mute/Vibration | |
| Waterpfoof Level | IP68 | |
| Compatible System | Android 4.4 and above,iOS 8.2 and above | |
| Special Features | Independent accurate oxygen, temperature, ECG, respiration rate, blood pressure, heart rate, blood oxygen, AI medical diagnosis, remote relatives and friends care | |
| Care Functions | Can share real-time data with families | |
| Main Feature | Electrocardiogram function, AI medical diagnosis, temperature monitoring, oxyhemoglobin monitoring, respiratory rate. Exercise function: step count/calorie/distance, Multiple motion mode. Heart rate monitoring, blood pressure monitoring and other health functions Remote relatives and friends care function Environmentally friendly TPU/ leather strap, no feeling to wear Wearable Hardware+Smart APP+ Big Data Cloud Services Wear it with you and use the APP to manipulate, display, and record data. Long endurance standby. Multi-dial switching | |
| Other Functions | Step,Calories,Distance,sleep monitor ,sport,Call reminder ,Alarm Reminder ,Raise you hand the watch lightr,Social share(wechat,QQ,Facebook,Twitter, shake hand to take phonto | |
| Screen Size | 1.70 inch HD color screen TFT 240*280 | |
| Screen Type | IPS TFT | |
| BLuetooth | 4.2BLE(Low power) | |
| Battery Type | Polymeter Lithium Battery | |
| Battery Capcaity | 200mAh | |
| Charging Type | Magnetic attraction (with short circuit protection circuit) | |
| Charging Time | About 3-4 hours | |
| Endurance Time | Use 7-15 days, standby 30-40 days | |
| Manipulation Mode | Full touch control, mobile phone APP control | |
| Language | Bracelet languages: Chinese, English, Traditional, Japanese, French, German, Italy, Spain, Russia, Portugal, Malay, Korean, Poland APP languages: Chinese, traditional, English, Japanese, german, Russian, Italian, French, Spanish, Portuguese, Thai, Czech, Greek, polish, Vietnamese, Turkish, Romanian, Hungarian, Danish, Finnish, Arabic, Ukrainian, Hebrew, Farsi, Irish, Slovak, Norwegian, Korean, croatian, Swedish | |
| Material | Enclosure: metal alloy+stainless steel Bottom shell: PC+ABS+ medical 316 steel sheet Strap: environmental protection TPU/ leather strap/ Metal watchband | |
| Color | 6 color schemes (TPU black, red and blue, leather black, leather brown, metal black) | |
Our Service
1) OEM is warmly welcome! We offer free watch OEM software screen logo, Laser engraved logo, OEM package and manual. OEM MOQ is 1000pcs.
2) All our production conducted full testing in our production line prior packaging.
3) We not charge any extra cost for samples, cost are negotiation.
4) 24*7 online technical supports.
Warranty
1. We guarantee the warranty policy of all our products is one year after shipping, except the artificial damaged. We will fix the item or replace new ones once after receiving the return items.
2. We have after-sales server team and online technical support team , please kindly feel free contact us for any question or comments, you can easy reach us on our office landline or send us email or online whatsapp or wechat.
FAQ
*What's the MOQ and lead time?
1.We don't have strict MOQ, samples or trial order is available anytime. OEM is 1000pcs, we are negotiable with you.
2.Our sample lead time 2-3days, our production lead time is 10-15days, also based on the order quantity.
*How can I get a sample to check quality?
Please kindly forward us the sample order summary (include the exact item style number, preferred colors, sample quantity), then we will make the sample PI for your approval include the pre-paid freight charge through international courier door to door for your approval, after received your payment, we will send you the sample dispatch and advise you the tracking number .Our payment method is ok through PayPal , Western Union /Moneygram or Bank transaction.
*When can I get the prices?
We guarantee we send you complete e-mail offer within 12 hours after we receive your inquiries.
If any question or comments, please kindly feel free to contact us.
Shenzhen Yushengchang Technology Company is a reliable GPS manufacturer, we are specialized in different
collections GPS tracker for kids, girls, lady, women safety, pets security, senior healthcare, vehicle fleet
management monitoring and assets security tracker. For more information, please kindly visit our website
and contact us for test demo:
https://www.4p-touch.com
